Applications
- Pump guide bushings
- Bearing bushings
- Throat bushings when specified
- Bronze or stainless pump bushings
- Pump repair and replacement
- OEM and aftermarket spare-part supply
Pump bushings and guide bushings
Custom Pump Bushings Made to Drawings or Samples
Drawing-based 304 pump bushings or bearing bushings in small batch
Drawing-based pump bushings and guide bushings for bearing, guide or throat-bushing requirements. Throat bushing is used only when the customer drawing or pump-seal-chamber context defines that application.
- Pump bushings
- Bronze / stainless
- Drawing-based
Application and function
Pump bushings provide controlled bore, fit and wear surfaces in pump support, guide or seal-chamber areas. The exact function depends on the customer's drawing, assembly position and operating context.
Common names
- Pump bushing
- Guide bushing
- Bearing bushing
- Bronze pump bushing
- Stainless steel pump bushing
- Throat bushing when specified by the drawing
Common materials
- Bronze / brass
- 304 / 316L
- Duplex 2205
- 2Cr13 / 20Cr13
- 3Cr13 / 30Cr13
- Customer-specified materials
Buyer concerns
- Bore size and roundness
- OD fit
- Wall thickness
- Grooves or lubrication features when specified
- Material compatibility
- Wear and corrosion resistance
In-house processes
- CNC turning
- ID and OD machining
- Groove machining when specified
- Drilling and tapping when specified
- Stellite 6 / ST6 welded hardfacing when accepted after in-house feasibility review
Partner processes
- Grinding
- Heat Treatment
- Nitriding / QPQ
- Other overlay requirements when specified
- Thermal Spray Coating
Key inspection items
- Bore
- OD
- Length
- Wall thickness
- Roundness
- Surface roughness
- Groove dimensions when specified
- Hardness when required
Documents available upon request
- Material certificate upon request
- First article report upon request
- Key-dimension inspection record
- Surface-treatment record when applicable
- Packing photos upon request
RFQ details to include
- Drawing, sample photos or assembly position
- Material grade and quantity
- Bore and OD fit requirements
- Groove, lubrication or throat-bushing details when applicable
- Inspection requirements
Buyer FAQs
What is the difference between a pump bushing and a shaft sleeve?
A pump bushing is usually a stationary support, guide or wear component with a controlled bore. A pump shaft sleeve is normally fitted around the shaft to protect sealing or packing areas.
Can RF Machining make bronze pump bushings?
Yes. Bronze, brass, stainless steel and customer-specified materials can be quoted from the drawing, sample and application requirements.
Do you make throat bushings?
Throat bushings can be quoted when the customer drawing or seal-chamber context identifies the part as a throat bushing. We avoid using that term for unrelated bushing parts.
Related components
Request for quotation
Send drawings or sample information
Send your drawing or sample information together with material, quantity, surface-treatment and inspection requirements. Our team will review the request and reply as soon as possible.
RFQ details to include
- Drawing or sample information
- Material requirements
- Order quantity
- Surface-treatment requirements
- Inspection requirements
- Target delivery timing
